OWON HDS25 デジタルオシロスコープ (2CH; 25MHz, 250MSa/s)

Oscilloscope Specifications:

Model: HDS25

Bandwidth: 25MHz

Channels: 2-CH Oscilloscope

Sample Rate: 250MSa/s

Acquisition Model: Normal, Peak detect

Record Length: 8K

Display: 3.5-inch LCD

Waveform Refresh Rate: 10,000 wfrms/s

Input Coupling: DC, AC, and Ground

Input Impedance: 1 MΩ±2%, in parallel with 16pF±10pF

Probe Attenuation Factors: 1X,10X,100X,1000X,10000X

Max. input Voltage: 400V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation)

Bandwidth Limit (typical): 20MHz

Horizontal Scale: 5ns/div - 1000s/div, step by 1 - 2 - 5

Vertical Sensitivity: 10mV/div - 10V/div

Vertical Resolution: 8 bits

Trigger Type: Edge

Trigger Modes: Auto, Normal, single

Automatic Measurement: Frequency, Period, Amplitude, Max, Min, Mean, PK-PK

Cursor Measurement: ΔV, ΔT, ΔT&ΔV between cursors

Communication Interface: USB Type-C

Multimeter Specifications (Standard):

Max. Resolution: 20,000 counts

Testing Mode: Voltage, Current, Resistance, Capacitance, Diode ,and Continuity test

Input Impedance: 10MΩ

Max Input Voltage: AC 750V, DC 1000V

Max Input Current: DC : 10A AC : 10A

Diode: 0 - 2V
